CAT40 1.25 END MILL TOOL HOLDER 1.25-2.5 $109.45
CAT40 1.25 END MILL TOOL HOLDER 1.25-2.5
Click to enlarge

CAT40 1.25 END MILL TOOL HOLDER 1.25-2.5
Click to enlarge 		CAT40 1.25 END MILL TOOL HOLDER 1.25-2.5
Click to enlarge
CAT40 1.25 END MILL TOOL HOLDER 1.25-2.5
Click to enlarge
Item No. CAT40-EM1.25-2.5
Price: $109.45
Shipping: In Stock - Ships Same Day *
Quantity:

* Same Day Shipping is only available on orders placed Monday - Friday before 4 P.M. Central Time.
Available Downloads for CAT40-EM1.25-2.5
STP file  DWG file  DXF file  PDF file
Product Info

View complete catalog page

  • Works on all CAT 40 Machines
  • This holder accepts all 1.25" shank tooling
  • Max shank depth is 2.75"
  • Nose diameter is 2.5 Inches
  • All critical surfaces precision ground
  • Made from alloy steel hardened to 54 - 56rc
  • Balanced to G2.5 at 20,000 rpms
  • Gage length is 2.5 inches
  • Concentricity is less than .0001
  • Rear thread for pull stud is 5/8-11
  • MariTool Part# is CAT40-EM1.25-2.5
Product Specifications
Balance Spec:  G2.5 @ 20,000 rpms
Concentricity:  .0001
Finish:  Black Oxide
Gage Length:  2.50
Material:  Hardened Alloy Steel
Nose Diameter:  2.5 Inches
Rear Thread:  5/8-11
Shank Size:  1.25
Taper:  CAT40
