Hydraulic Holders have the best dampening abilities of all holders resulting in....

• Minimal noise emissions
• Increased tool life
• Improved surface finish and less chatter
• Less chipping of sharp corner tooling

Product Details

• These holders are maintenance free
• Fast tool change, simply insert tool and tighten screw until it stops
• This Tool Holder has a thru hole, coolant thru capable
• Maximum operating temperature 120 deg Fahrenheit
• Super accurate .0001 TIR or less at 4x diameter
• Balanced to G2.5 @ 25,000 rpms
• For .125 shank tooling only
• Unlimited shank depth, this holder does not have a rear stop
• Shank must be inserted min .500" deep for proper clamping
• 4mm allen key is not included but available here
• View BT30 Pull Studs
