- Torque Ratings for SK10 Collet Nuts can be found here
- With SK10-HT nut high metal removal rates are possible without shank slippage
- Collet Chuck accepts all SK10 collets
- Works on all BT30 machines with Dual Contact Spindles
- Compatible with BIG-PLUS® spindles
- Threaded for stop screw type 1 (not included)
- All critical tool holder surfaces precision ground
- Made from alloy steel hardened to 54 - 56rc
- Tool Holder is balanced to G2.5 at 20,000 rpms
- Gage length is 60mm (2.3 inches)
- Concentricity is less than .0001 at collet face
- Collet nut is included
- Uses HT10-TWA torque wrench adaptor (not included)
- We also recommend CTW-10-150 torque wrench for proper tightening
- Coolant thru capability
- Rear thread for pull stud is m12 x 1.75
- MariTool Part# is BT30-SK10-60D-HT
*BIG-PLUS® is a trademark of Daishowa Seiki Kabushiki Kaisha; Big Daishowa Seiki Co., Ltd., Corp.
Compatible with BIG-PLUS® spindles, but not licensed.
