• Reamers are ideal for tight tolerance applications
• Left hand spiral is ideal for better roundness and reaming holes with intersecting side holes or other features
• Excellent for reaming Alum, brass, all steels, Stainless, Inconel, and Bronze
• 45° chamfer lead
• Solid Carbide - Right Hand Cut -Left hand 10 deg spiral

Coating:	Uncoated
Cutting Diameter:	.0622 (1.58mm)
Cutting Diameter Tolerance:	-.0000/+.00012
End Style:	45 deg chamfer lead
Flute Length:	.433
Helix Angle:	left spiral / right hand cut
Material:	Solid Carbide
Number of Flutes:	4 flute 10deg spiral
Reamer l2 length:	1.220
Shank Size:	.0622
Total Length:	1.97 Inches
